Morion高指标恒温晶振MV341-A5E-10.0M-ULN-1.5E-13

MV341-A5E-10.0M-ULN-1.5E-13晶振指标

具体指标如下:

温度范围：

工作温度: 0-55℃  (±5x10E-9)

Storage temperature range: -55 to +85℃

老化：

±3x10E-8/年

频率：

10MHz

相噪(超低相噪)：

         <-89 to -90dBc/Hz@0.1Hz

         <-119 to -120dBc/Hz@1Hz

         <-145 dBc/Hz@10Hz

<-157 dBc/Hz@100Hz

         <-160dBc/Hz@1000Hz

         <-167dBc/Hz@10000Hz

短稳(阿仑方差):

per 1 sec: 1.5E-13

目前4周内可交货的是3E-13

振动(10-500Hz)：

         Acceleration: 5g

         Shock: 75g/3±1ms

         Humidity(@25℃): 98%

Frequency stability vs. load changes (±5%):

         <±5 X 10E-10

Frequency stability vs. power supply changes (±5%):

         <±5 X 10E-10

Warm-up time within accuracy of <±2x10-8@25℃:

         <5min

Power supply (Us):

         12V±5%

Steady state current consumption @ +25℃:

         <250mA

Peak current consumption during warm-up (温度>20℃):

         <600mA

Frequency pulling range:

         >±3 X 10E-7

Control voltage range (Uin):

         0 – 5 V

Reference voltage (Uref):

         +5 V

Output:

         SIN

Level:

         >400mV

Load:

         50 Ohm±5%

Harmonics:

         >30dBc

封装: Z16

Morion晶振MV341系列选型手册下载: 34-MV341_REV.13_2019.pdf
